RUSHMORE USA 100369 17/32" Size, 1-1/8" LOC, 2 Flute, High Speed Steel 2 Flute Finishing End Mill
by Rushmore USA
$38.18
SKU 08-034-160
| Product Specifications | |
|---|---|
| Brand | RUSHMORE USA |
| Shank Diameter | 1/2" |
| Overall Length | 3-1/8" |
| Finish Coating | Bright |
| Size Type | Fractional |
| Size | 17/32" |
| No. of Flutes | 2 |
| Length of Cut | 1-1/8" |
| Tool Material | High Speed Steel |
| Single or Double End | Single |
| Helix Angle | 30° |
| Center Cutting | Yes |
| Type | 2 Flute High Speed Steel Single End Mill |
| Model # | 100369 |
| Cutting Direction | Right Hand |
| First Choice For: | Non-Ferrous |
| Flute Shape | Spiral Flute |
| Hardness | 58 to 60 RC |
| Length Type | Standard Length |
| Prop. 65 | Yes |
| Shank Style | Straight Shank |
| Tolerance_Cutting Diameter | +.002/-.000" |
| Tolerance_Shank Diameter | -0.0001"/ -0.0005" |
| UNSPSC | 27112803 |
| Weight | 0.3 lbs. |
| Workpiece Material Range | Steel, Non-Ferrous, Cast Iron, Plastics |
| Country of Origin | UNITED STATES OF AMERICA |
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Applications
- For general milling operations for slots, grooves and other similar features.
- For use in machine tools.
- For use on a variety of ferrous and non-ferrous materials.
Features
- Right hand (clockwise rotation) cutting direction.
- The spiral flute design permits a faster and smoother cutting action and the end mills are sized to provide a good cutting range while affording adequate rigidity.
Technical Data
- Manufactured from high speed steel.
- Ground from the solid.
- Bright finish.
