RUSHMORE USA 100181 11/32" Size, 7/8" LOC, 4 Flute, Bright Solid Carbide Finishing End Mill
by Rushmore USA
$39.04
SKU 08-600-057
| Product Specifications | |
|---|---|
| Brand | RUSHMORE USA |
| Shank Diameter | 3/8" |
| Overall Length | 2-1/2" |
| Finish Coating | Bright |
| Size Type | Fractional |
| Size | 11/32" |
| No. of Flutes | 4 |
| Length of Cut | 7/8" |
| Tool Material | Solid Carbide |
| Single or Double End | Single |
| Helix Angle | 40° |
| Center Cutting | Yes |
| Type | 4 Flute Micrograin Solid Carbide Single End Mill |
| Corner Radius | 0 |
| Flute Length | 7/8" |
| Model # | 100181 |
| Application | Center cutting style allows for 3 axis profile milling, plunging and ramping. For profiling, slotting of stainless steel and exotic materials. |
| Cutting Direction | Right Hand |
| First Choice For: | Non-Ferrous |
| Flute Shape | Spiral Flute |
| Helix Angle & Style | 40° Helix |
| Material To Be Machined | Stainless steel and exotic materials |
| Prop. 65 | Yes |
| Shank Style | Straight Shank |
| TIR Maximum | .005" |
| Tolerance_Cutting Diameter | +.000" / -.003" |
| Tolerance_Shank Diameter | -.0001"/-.0004" |
| UNSPSC | 27112803 |
| Weight | 0.55 lbs. |
| Workpiece Material | Stainless steel and exotic materials |
| Workpiece Material Range | Steel, Stainless Steel, High-Temp Exotic Alloys, Non-Ferrous, Cast Iron, Hard Materials, Plastics |
| Country of Origin | UNITED STATES OF AMERICA |
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
Applications
Center cutting style allows for 3 axis profile milling, plunging and ramping. For profiling, slotting of stainless steel and exotic materials.Features
- Manufactured from 10% cobalt premium micrograin tungsten carbide with an advanced tool geometry that will outperform conventional end mills.
- 40° helix provides a higher shearing action with superb workpiece finish.
- Chip ejection is greatly improved and allows use of higher feeds and speeds on stainless steel and heat-treated materials.
- Higher rake and helix.
