| Product Specifications | |
|---|---|
| Brand | RUSHMORE USA |
| Size Type | Fractional |
| Size | 1/4" |
| Drill Point Angle | 140° |
| Tool Material | Solid Carbide |
| Finish Coating | Bright |
| Shank Diameter | 0.315" |
| Overall Length | 3.58" |
| Flute Length | 2.086" |
| Cutting Direction | Right Hand |
| Model # | 101358 |
| Helix Angle | 30° |
| Application | Holemaking |
| Decimal Size | 0.25" |
| Drill Type | 5XD Carbide Drill |
| Drop Ship | † |
| Flute Shape | Standard Spiral, Helical Flute |
| Hole Depth | 5XD |
| Must Buy | Must Buy 2 Pcs. |
| No. of Flutes | 2 |
| Prop. 65 | Yes |
| Shank Style | Common Straight Shank |
| Single or Double End | Single |
| Tolerance_Cutting Diameter | +.0008" / +.0002" |
| Tolerance_Overall Length | +/-.060" |
| Tolerance_Shank Diameter | +.0000" / -.0003" |
| UNSPSC | 23241634 |
| Weight | 0.095 lbs. |
| Workpiece Material | Hardened, Cast Iron, Titanium, Non-Ferrous, Stainless Steel & Steel |
| Country of Origin | UNITED STATES OF AMERICA |
WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov
